Adjustable Alley Gate
For use between any section of alley panels in an adjustable alley, this heavy duty roll gate can be used to block cattle and provide alley support.
← Back to Products
Priefert’s durable Adjustable Alley Gate is designed for use with our Premier, Rough Stock Open, and Solid Sweep Systems. The AAG20 serves as a heavy duty roll gate for blocking cattle. Designed to work with the standard Adjustable Alley Frame, the alley can be adjusted to one of four widths to better fit the size of cattle being worked. Sturdy pin connectors on the frame secure the AAG20 to the alley panels. This product features an Architectural Grade Powder Coat finish to help it resist rust and scratching, while UV inhibitors in the powder help the adjustable alley frame gate resist fading, ensuring that your product holds up well and looks great for many years to come.
- Overall Width: 43.5” (including handle)
- Weight: 248 lbs (All weights approximate)
- Frame constructed from 2” OD 11 gauge tubing
- Gate sheeted with 16 gauge steel
- The Sheeted Adjustable Alley Gates are designed to work with our Adjustable Alley Frames and serve as heavy duty roll gates for blocking cattle.
- Priefert’s unique Adjustable Alley Frames and Adjustable Alley Gate allow operators to quickly and easily adjust the width of the working alley to better fit the size of cattle being worked.
- The inside alley width can be set to 18”, 21”, 25”, or 28” wide. The frame-to-panel connection is fixed on one side of the gate’s frame, while the connection point on the other side is adjustable. By using the adjustment handle on the side of the gate frame, the operator is able to slide the panel connection point in or out to effectively change the alley width.
- This Adjustable Alley Gate frames help maintain the strength and integrity of your alley.
- Sturdy pin connectors are used to secure the Adjustable Alley Gate to the panels of the alley.
- These bolt on pin connectors can be adjusted to fit a variety of setups.
