8' Sheeted Curved Panel
Item # scp

8' Sheeted Curved Panel

An essential sweep component, this sheeted curved panel includes three vertical blocking points for the sweep gate’s spring-loaded latch.

← Back to Products
Description
Specially designed for use in constructing the sweep tub in Priefert’s Solid Sweeps, the SCP includes three vertical blocking points that allow the sweep gate to continually latch as it “sweeps” forward. These stops help prevent cattle from pushing the sweep gate back when being crowded. This panel also features sturdy Rough Stock pin connectors for quick and secure attachments. The Architectural Grade Powder Coat Finish helps the product to resist rust, scratches, and fading to add years of life to your investment.
Images
Specifications
  • Weight: 187 lbs (All weights approximate)
  • Solid bottom of the panel is constructed from 14 gauge sheeted steel
  • When properly installed, the sheeting begins 10” above ground and continues to 51” above the ground
Features
  • Specially designed for use in Priefert’s Solid Sweep, this curved panel makes up the sweep tub.
  • Each SCP includes three vertical blocking points that allow the sweep gate to continually latch as it “sweeps” forward. These stops help prevent cattle from pushing the sweep gate back when being crowded.
  • The solid bottom of the panel begins 10” above ground and continues to 51” above the ground.
